Semi-automatic barrel zine plating line

Our main products include various types of roll forming machine, pipe processing machine, wire drawing machine, lathe and other related machines, etc.

Commodity name： Semi-automatic barrel zine plating line

Category:

Email:

Phone:

Description

Specification

Item	Parameter	QTY
High temperature degreasing tank	Inner size : 12008001000mm	1 set
	15mm PP Plate Welding
	Strengthen: 2 layers 40*60mm square pipe
	Quartz heating tube : 2 pcs
Rinse tank	Inner size : 12008001000mm	2 set
	15mm PP Plate Welding
	Strengthen: 2 layers 40*60mm square pipe
Activation Tank	Inner size : 12008001000mm	1 set
	15mm PP Plate Welding
	Strengthen: 2 layers 40*60mm square pipe
Rinse tank	Inner size : 12008001000mm	1 set
	15mm PP Plate Welding
	Strengthen: 2 layers 40*60mm square pipe
Zinc plating tank	Inner size : 120016001000mm	2 set
	15mm PP Plate Welding
	Strengthen: 2 layers 40*60mm square pipe
Rinse tank	Inner size : 12008001000mm	2 set
	15mm PP Plate Welding
	Strengthen: 2 layers 40*60mm square pipe
Brighter Dipping Tank	Inner size : 12008001000mm	1 set
	15mm PP Plate Welding
	Strengthen: 2 layers 40*60mm square pipe
Rinse tank	Inner size : 12008001000mm	1 set
	15mm PP Plate Welding
	Strengthen: 2 layers 40*60mm square pipe
Passivation tank	Inner size : 12008001000mm	1 set
	15mm PP Plate Welding
	Strengthen: 2 layers 40*60mm square pipe
Rinse tank	Inner size : 12008001000mm	1 set
	15mm PP Plate Welding
	Strengthen: 2 layers 40*60mm square pipe
Hot water rinse tank	Inner size : 12008001000mm	1 set
	15mm PP Plate Welding
	Strengthen: 2 layers 40*60mm square pipe
	Quartz heating tube : 2 pcs
Plating barrel	Size : 1000*500mm	7 pcs
	Aerylic Plate and Copper conductive rod
Rectifier	3000A 12V	1 set
	Air cooling
	Input voltage : 380V 50HZ
Semi-automatic Crane lifting	Metal frame	2 sets
	Motor
Main machine frame and track	Metal frame	1 set

Optional Item

Filter	330L/min	1 set
Filter	Input voltage : 380V 50HZ	1 set
Dry machine	With heating system	1 set
Chemical material	Anode plate :Zinc plate	6 pcs
	Chemical solution (Pure water mixed ):
	KCL,ZnCl2,H3BO3,Softer,Brightener

Plating process

High temperature degreasing -- Rinse -- Rinse -- Activation -- Rinse -- Rinse -- Zinc plating -- Rinse -- Rinse -- Brighter Dipping -- Rinse -- Passivation -- Rinse --- Hot water rinsing
