Wire Coil Shot blasting machine

Our main products include various types of roll forming machine, pipe processing machine, wire drawing machine, lathe and other related machines, etc.

  • Commodity name： Wire Coil Shot blasting machine

Category:

Shot Blasting Machine

Email:

info@sjzaisen.com

Phone:

+86-15100123091

Get Quote
Relevant
  • Description

  • User Coil Information:
    Material: SAE 1006, 1010, 1015, 1020, 1025, 1045, 10B21, 10B22, 10B30, 10B33, 8620, 5135, 5140, 4140, 16MnCr5, 41Cr4.
    Diameter: 6.5mm~34mm
    Coils:
    Internal diameter: Minimum: 750mm / Maximum: 900mm
    External diameter: Minimum: 1200mm / Maximum 1500mm
    Weight: Smallest: 1.0ton / Largest: 2.5ton
    Height: 1050mm.


    Main Technical Specification:
    Material to be blasted: Carbon structural steel, alloy structural steel, caron tool steel, spring steel, bearing steel, high speed tool steel, stainless steel (austenitic ferritic, martensitic), alloy tool steel.
    Wire range diameter: 6.5 to 34mm, smaller (6.5mm) or bigger (34mm) diameters are possible to be blasted as a sufficient spread can be done.
    Coil outside diameter max.: 1500mm
    Coil inside diameter min.: 750mm
    Length of coil arms:4200 5500mm

    Coil weight diameter max.

    Diameter 6.5-8mm10-12mm14mm16mm20mm30mm34mm
    Weight Kg1800220022002500250025002500









    Turbines: 8 no.                 22 KW (Frequency converter adjustment)
    Coil arms: 2 no.                4K W (Frequency converter adjustment)
    Bottom screw conveyor: 2 no.   7.5 KW
    Top Screw conveyor: 2 no.      5.5 KW
    Bucket Elevator: 2 no.           7.5 KW
    Door rotation: 1 no.             4 KW (Frequency converter adjustment)
    Dust Collector Fan: 1 no.        30 KW

Company Profile

Shijiazhuang Aisen Machinery Co., Ltd. Is a professional company for metal processing machinery, Our main products include various types of roll forming machine, pipe processing machine, wire drawing machine, lathe and other related machines, etc.

Our company regards"reasonable prices, high quality and good after-sales"as our tenet. Got great feedback and honor from all the clients. Our products were sold to more than 20 countries already. We hope to cooperate with more customers for mutual development and benefits. You are welcome to contact us!





Honor

Workshop

Customer photo

Loading & Shipping
